Newland FM430 Barracuda
Newland FM430 Barracuda
Available stock: 5
-
Estimated delivery: Nov 01 - Nov 05
Share this product
Couldn't load pickup availability
Infomation
Infomation
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Scanning | |
|---|---|
| Type | Fixed bar code reader |
| Scanner type | 1D/2D |
| Sensor type | CMOS |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, ITF-14, ITF-6, Industrial 2 of 5, MSI, Matrix 2 of 5, Plessey, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Code 1, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code |
| Optical sensor resolution (W x H) | 1280 x 800 pixels |
| Read rate (max) | 60 reads/s |
| Tilt reading angle | -55 - 55° |
| Pitch reading angle | -55 - 55° |
| Yaw reading angle | 0 - 360° |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Standard interfaces | USB |
| Cable length | 0.5 m |
| Performance | |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| International Protection (IP) code | IP54 |
| Protection features | Drop proof, Electrostatic Discharge (ESD) protection |
| Buzzer | Yes |
| Print contrast | 25% |
| Built-in processor | Yes |
| Processor frequency | 1000 MHz |
| Product colour | Black |
| Certification | FCC Part15 Class B, CE EMC Class B, IEC60825, IEC62471, KC |
| Power | |
| Power source type | USB |
| Input voltage | 100 - 240 V |
| Input frequency | 50 - 60 Hz |
| AC adapter output voltage | 5 V |
| Power consumption | 276.8 mA |
| Weight & dimensions | |
| Width | 41.5 mm |
| Depth | 49.5 mm |
| Height | 24.3 mm |
| Weight | 75 g |
| Packaging data | |
| Cables included | USB |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Compliance certificates | RoHS |
