Uninterruptible Power Supply Eaton 9PX 5000i 5 kVA 5000W 100V-276V RT3U - 9PX5KIRTNG2
Uninterruptible Power Supply Eaton 9PX 5000i 5 kVA 5000W 100V-276V RT3U - 9PX5KIRTNG2The Eaton 9PX 5000i RT3U Netpack G2 is designed for critical systems that require reliable power backup with a double-conversion online architecture.
Delivering 5 kVA and 5000 W, this UPS ensures continuous sine wave output with input voltage options of 100 V to 276 V for varying deployment needs.
- Type: Double-conversion (Online)
- Power capacity: 5 kVA
- Output power: 5000 W
- Output waveform: Sine
- Input voltage range: 100 V - 276 V
This solution is ideal for IT admins managing power supply needs for server rooms and network infrastructure.
Available stock: 1
-
Estimated delivery: Oct 13 - Oct 17
Share this product
Couldn't load pickup availability
Informations
Informations
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 5000 W |
| Waveform | Sine |
| Input operation voltage (min) | 100 V |
| Input operation voltage (max) | 276 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Power consumption (average operating) | 165 W |
| Heat dissipation | 563 BTU/h |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 96.7% |
| Efficiency (ECO mode) | 99% |
| Input power factor | 0.99 |
| Noise level | 40 dB |
| Ports & interfaces | |
| AC outlet types | C13 coupler, Hardwire, C39 coupler |
| USB port | Yes |
| RS-232 ports | 1 |
| Network card slot | Yes |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 5 Ah |
| Battery voltage | 12 V |
| Typical backup time at half load | 9.4 min |
| Automatic battery test | Yes |
| Design | |
| Form factor | Rackmount/Tower |
| Rack capacity | 3U |
| Cable length | 1.8 m |
| Product colour | Black, Silver |
| Display type | LCD |
| LED indicators | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Certificates | |
| Compliance certificates | CB, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD), RCM, REACH, RoHS, UKCA, WEEE, cULus |
| Certification | IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 |
| Packaging content | |
| Cables included | USB cable |
| Quick installation guide | Yes |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 440 mm |
| Depth | 684 mm |
| Height | 130 mm |
| Weight | 43.1 kg |
