Management features
Switch type Managed
Switch layer L2
Quality of Service (QoS) support Yes
Web-based management Yes
ARP inspection Yes
Configuring Location Settings (CLI) Yes
System event log Yes
MIB support Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity 4
Power connector AC-in jack
Network
Networking standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring Yes
Full duplex Yes
Flow control support Yes
Link aggregation Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
Spanning tree protocol Yes
Head-of-line (HOL) blocking Yes
Auto-negotiation Yes
VLAN support Yes
Number of VLANs 256
Data transmission
Switching capacity 56 Gbit/s
Forwarding rate 41.7 Mpps
MAC address table 8000 entries
Store-and-forward Yes
Jumbo frames support Yes
Jumbo frames 10000
Packet buffer memory 4.1 MB
Security
DHCP features DHCP server, DHCP client
Access Control List (ACL) Yes
IGMP snooping Yes
MAC address filtering Yes
Loop protection Yes
Multicast features
Multicast support Yes
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
LED indicators Yes
Number of fans 2 fan(s)
Performance
Memory type DDR3-SDRAM
Internal memory 256 MB
Flash memory 32 MB
Noise level 51.7 dB
Mean time between failures (MTBF) 469262 h
Power
Power source AC
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Power consumption (max) 236.9 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) ports quantity 24
Total Power over Ethernet (PoE) budget 193 W
Operational conditions
Operating temperature (T-T) -5 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Heat dissipation 900.36 BTU/h
Weight & dimensions
Width 440 mm
Depth 140 mm
Height 44 mm
Weight 2.15 kg
