Management features
Switch type Managed
Switch layer L2/L3
Quality of Service (QoS) support Yes
Cloud-managed Yes
ARP inspection Yes
Configuring Location Settings (CLI) Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports type No
SFP+ module slots quantity 24
Console port RJ-45/Micro-USB
QSFP28 ports quantity 2
USB 2.0 ports quantity 2
Network
Networking standards IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3aq, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bm, IEEE 802.3bt, IEEE 802.3by, IEEE 802.3bz
10G support No
Copper ethernet cabling technology 1000BASE-T
Ethernet LAN data rates 10,100,1000 Mbit/s
VLAN support Yes
Number of VLANs 4094
Data transmission
Switching capacity 1080 Gbit/s
Forwarding rate 803.5 Mpps
Security
Access Control List (ACL) Yes
Access Control List (ACL) egress 1024
Access Control List (ACL) ingress 9216
Multicast features
Multicast support Yes
Protocols
Supported network protocols IPv4, IPv6
Design
Rack mounting Yes
Stackable Yes
Product colour Purple
Performance
Noise level 40.6 dB
Power
Power source AC
Power supply included Yes
Number of power supply units 1
AC input voltage 100 - 240 V
AC input frequency 47/63 Hz
Power consumption (max) 171 W
Power over Ethernet (PoE)
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 10 - 95%
Storage relative humidity (H-H) 10 - 95%
Operating altitude 0 - 3000 m
Heat dissipation 585 BTU/h
Weight & dimensions
Width 441 mm
Depth 442 mm
Height 44 mm
Weight 6.25 kg
Sustainability
Sustainability compliance Yes
Certificates
Compliance certificates REACH, RoHS, WEEE
Certification CISPR 32, Class A (International Emissions) AS/NZS CISPR32 CISPR 24 Class A (International Immunity) IEC 61000-4-2/EN 61000-4-2 Electrostatic Discharge, 8kV Contact, 15 kV Air, Criteria B IEC 61000-4-3 /EN 61000-4-3 Radiated Immunity 10V/m, Criteria A IEC 61000-4-4/EN 61000-4-4 Transient Burst, 1 kV, Criteria AB IEC 61000-4-5 /EN 61000-4-5 Surge, 2 kV L-L, 2 kV L-G, Level 3, Criteria B IEC 61000-4-6 Conducted Immunity, 0.15-80 MHz, 10V/m unmod. RMS, Criteria A IEC/EN 61000-4-11 Power Dips & Interruptions, >30%, 25 periods, Criteria C
