Performance
Total megapixels 5 MP
Temperature measurement range -10 - 50 °C
Horizontal field of view 34°
Vertical field of view 24°
Infrared spectral band 7.5 - 14 µm
Thermal frame rate 9 Hz
Thermal sensitivity (NETD) 75 mK
IFOV (spatial resolution) 0.93 mRad
Accuracy 2 °C
Built-in laser pointer Yes
Level/span Auto/Manual
Lens system
Closest focusing distance 0.15 m
Design
Product colour Black, Yellow
Built-in display Yes
Display type LCD
Display diagonal 8.89 cm (3.5")
Display resolution 640 x 480 pixels
Touchscreen Yes
Operating temperature (T-T) -10 - 50 °C
Storage temperature (T-T) -20 - 50 °C
Operating relative humidity (H-H) 10 - 95%
Features
Card reader integrated Yes
Compatible memory cards MicroSD (TransFlash)
Maximum memory card size 4 GB
Image formats supported BMP, JPEG
Battery
Battery technology Lithium-Ion (Li-Ion)
Battery recharge time 2.5 h
Battery life (max) 3 h
Power
Input voltage 100 - 240 V
Weight & dimensions
Width 122 mm
Depth 167 mm
Height 277 mm
Weight 1.04 kg
Technical details
Compliance certificates RoHS
