Storage
Storage drive capacity 0 GB
Supported storage drive interfaces Serial ATA III, Serial Attached SCSI (SAS)
RAID support Yes
Hot-swap drive bays Yes
Supported file systems BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed No
Total installed storage capacity 0 TB
Number of storage drives supported 24
Installed storage drive type No
Supported storage drive types HDD & SSD
Processor
Processor manufacturer Intel
Processor family Intel® Xeon® D
Processor model D-1567
Processor frequency 2.1 GHz
Processor boost frequency 2.7 GHz
Processor cores 12
Processor threads 24
Processor cache 18 MB
L3 cache 18 MB
CPU configuration (max) 1
PCI Express configurations 1x16, 1x4, 1x8
PCI Express slots version 2.0, 3.0
Processor cache type L3
Processor code SR2M3
Processor codename Broadwell
Processor lithography 14 nm
Processor operating modes 64-bit
Processor package size 37.5 x 37.5 mm
Processor series Intel Xeon D-1500
Processor socket BGA 1667
Scalability 1S
Stepping Y0
Thermal Design Power (TDP) 65 W
Maximum internal memory supported by processor 128 GB
Conflict-Free processor Yes
Memory
Internal memory 16 GB
Internal memory type DDR4
Maximum RAM supported 128 GB
Memory slots 4
Memory form factor DIMM
Network
Ethernet LAN Yes
Ethernet LAN data rates 10,100,1000,10000 Mbit/s
iSCSI support Yes
Supported network protocols SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™, L2TP)
Dynamic DNS (DDNS) Yes
Ports & interfaces
USB port Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Ethernet LAN (RJ-45) ports 6
Design
Chassis type Rack (2U)
Cooling type Active
Product colour Black
Number of fans 4 fan(s)
Fan diameter 8 cm
Performance
Type NAS
Device class Small & Medium Business
Backup function Yes
Backup features Cloud, USB drive
Noise level 57 dB
Power
Power supply location Built-in
Power supply unit (PSU) capacity 500 W
Number of power supply units 1
Redundant power supply (RPS) support Yes
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Weight & dimensions
Width 482 mm
Depth 724 mm
Height 88 mm
Weight 14.9 kg
Processor special features
Embedded options available Yes
Enhanced Intel SpeedStep Technology Yes
Execute Disable Bit Yes
Idle States Yes
Intel 64 Yes
Intel Enhanced Halt State Yes
Intel Secure Key Technology version 1.00
Intel Trusted Execution Technology Yes
Intel TSX-NI Yes
Intel TSX-NI version 1.00
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® OS Guard Yes
Intel® Secure Key Yes
Intel® Turbo Boost Technology 2.0
Maximum number of PCI Express lanes 32
Thermal Monitoring Technologies Yes
UART Yes
Memory types supported by processor DDR3-SDRAM, DDR4-SDRAM
Operational conditions
Operating temperature (T-T) 0 - 35 °C
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -20 - 60 °C
Storage relative humidity (H-H) 5 - 95%
Logistics data
Harmonized System (HS) code 84714100
Other features
Compliance certificates RoHS
Processor ARK ID 93356
