Network
Maximum data transfer rate 1000 Mbit/s
Converter input interface 1000Base-T
Converter output interface 1000Base-SX
Performance
Maximum transfer distance 550 m
Wavelength 850 nm
Fiber mode structure Multi-mode
Fiber cable diameters supported (core/cladding) 50/125,62.5/125 µm
Tx power (min) -10 dBmW
Tx power (max) -4 dBmW
Sensitivity -17 dBmW
Link budget 7 dB
Features
Internal No
LED indicators Yes
Product colour Black
Ports & interfaces
Connectivity technology Wired
Ethernet LAN (RJ-45) ports 1
Fiber optic connector SC
Power
Power consumption (typical) 3.15 W
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -15 - 65 °C
Operating relative humidity (H-H) 5 - 95%
Operating altitude 0 - 3000 m
Packaging data
Package weight 900 g
Certificates
Certification FCC A, CISPR22/EN55022 A, EN55024, CE
Other features
Receive power 0.0 dBmW
Dimensions (WxDxH) 46 x 85 x 22 mm
